The 7kW Type-1 Portable Charger is a high-performance charging solution designed for American EVs and other vehicles compatible with the J1772 charger standard. This versatile portable EV charger offers fast and convenient charging at home, work, or on the go, making it the perfect EV charger for American cars. Built with durable materials and intelligent safety features, it ensures consistent performance in any environment. For added peace of mind, every unit is backed by a two-year warranty, giving you confidence in your investment.

Electrical Specifications:

• Input Voltage: 230V AC ±15%, 50Hz (Single-phase)
• Max Output Power: 7.4kW (32A continuous)
• Connector Type: SAE J1772 (Type-1)
• Cable: 5m tethered premium rubber cable, UL94 V-0 rated insulation
• Operating Temperature: -30°C to +50°C
• Enclosure Rating: IP65 – weatherproof for indoor and outdoor use

Safety Features:

• Overvoltage / Undervoltage Protection
• Overcurrent & Short-Circuit Protection
• Over-temperature Shutdown
• Ground Fault Protection (6mA DC)

Key Features:

• High-Power Portable Charging: Full 7.4kW charging through a robust 32A CEE plug for rapid EV charging anywhere
• Adjustable Current Settings: Easily select 6A, 10A, 16A, or 32A charging currents via the front touch panel to match available power
• Scheduled Charging: Set start and stop times to optimize charging during off-peak electricity periods
• Broad US EV Compatibility: Compatible with all North American-spec EVs equipped with Type-1 connectors, including Chevrolet, Ford, Nissan, and more
• Durable & Safe Design: IP65-rated enclosure and 6mA DC ground fault protection ensure safe, rugged operation in any environment
• Compact and Lightweight: Weighs just 3.8kg with a compact footprint (350×200×80mm) and convenient carry handle for easy portability

Package Contents:

• 7kW J1772 Portable EV Charger
• 5m Tethered Type-1 (J1772) Cable
• Protective Storage Bag
• Quick-Start User Manual

Installation Requirements:

• Professional installation required, including:
  • CEE 32A blue socket
  • 6mm² copper wiring
  • Dedicated 32A circuit breaker
• Not compatible with standard household outlets
